Engine
| Engine Model |
OM 926 |
| Maximum Power, kW |
210 kW @ 2200 rpm |
| Maximum Torque, Nm |
1100 Nm @ 1200 – 1600 rpm |
| No. of Cylinder, Displacement |
6 cylinder, 7200CC |
| Emission Standard |
Bharat stage VI – OBD-2 |
Gearbox
| Gear Box Model & Type |
G 131, 9F+1R, Mechanical, Synchromesh Gears |
| Clutch Type |
Single Dry Plate, Hydraulic Control |
| Clutch Dia, Wear (mm) |
430, 4.5 mm |
| Power Take Off |
Auxiliary Fitment |
Axle
| Front Axle |
IF 7.0 |
| Rear Axle |
IR440 (Single Reduction Axle) |
| Rear Axle Ratio |
4.3 |
[/vc_tta_section][vc_tta_section i_icon_fontawesome=”fas fa-truck” add_icon=”true” title=”Chassis Frame & Suspension” tab_id=”1724237516931-64958853-53c9″]
| Frame Section (D x W x T) (mm) |
288 x 70 x 9 |
| Front Suspension |
Parabolic Type Leaf Spring with 2 Hydraulic Shock Absorbers
|
| Rear Suspension |
Semi-Elliptical With Auxiliary Springs
|
| Anti-Roll Bar |
Front – Standard
|
[/vc_tta_section][vc_tta_section i_type=”linecons” i_icon_linecons=”vc_li vc_li-vynil” add_icon=”true” title=”Brakes” tab_id=”1724238753410-ff7f574e-cd12″]
| Service Brake |
Pneumatic, Foot Operated, Dual Line with ABS |
| Parking Brake |
Pneumatically Operated Hand Control Valve |
| Front Brake Size (mm) & Type |
Ø 410 drum |
| Rear Brake Size (mm) & Type |
Ø 410 drum |
[/vc_tta_section][vc_tta_section i_type=”openiconic” i_icon_openiconic=”vc-oi vc-oi-steering-wheel” add_icon=”true” title=”Cabin & Steering” tab_id=”1724238922181-924a6148-2ef4″]
| Cabin |
Sleeper Cabin |
| Steering Type |
Hydraulic Power Assisted |
[/vc_tta_section][vc_tta_section i_icon_fontawesome=”fas fa-car-battery” add_icon=”true” title=”Electrical System” tab_id=”1725259681516-016e9b91-f35d”]
| Battery Capacity (Ah) |
120Ah |
| Voltage (V) |
24V |
[/vc_tta_section][vc_tta_section i_type=”openiconic” i_icon_openiconic=”vc-oi vc-oi-aperture-alt” add_icon=”true” title=”Tyres” tab_id=”1724395498122-e7ec8058-5e92″]
| Pattern & Size |
Radial Tyres – 295/90R20 |
[/vc_tta_section][vc_tta_section i_icon_fontawesome=”fas fa-weight-hanging” add_icon=”true” title=”Weight” tab_id=”1724395570483-11b87397-61bc”]
| Gross Vehicle Weight – (kg) |
45500 kgs With Suitable Three Axle Trailer – Mechanical Suspension On All Three Trailer Axles |
[/vc_tta_section][vc_tta_section i_type=”typicons” i_icon_typicons=”typcn typcn-flow-switch” add_icon=”true” title=”Dimensions (mm): All Dimensions are for CBC” tab_id=”1724395588931-dc6e8c70-4c59″]
| Wheel Base (mm): |
3600 |
| Overall Length (mm): |
6065 |
| Overall Width (mm): |
2490 |
| Overall Height (mm) (CBC): |
2975 |
| Front Overhang (mm): |
1485 |
| Rear Overhang (mm): |
980 |
| Ground Clearance (mm): |
304 |
[/vc_tta_section][vc_tta_section i_icon_fontawesome=”fas fa-gas-pump” add_icon=”true” title=”Fuel” tab_id=”1724739121740-db03b7b0-c722″]
| Fuel Tank / Filling Capacity (L) |
455L/ 430L |
| Adblue Tank / Filling Capacity (L) |
60L/ 51L |
[/vc_tta_section][vc_tta_section i_icon_fontawesome=”fas fa-tachometer-alt” add_icon=”true” title=”Performance” tab_id=”1724395630292-a2215831-47f1″]
| TCD (m) |
13.1 m |
| Maximum Gradeability (%) |
30.50% |
| Maximum Geared Speed (kmph) |
80 kmph |
