Engine
| Engine Model |
4D34i |
| Maximum Power, kW |
125 kW @ 2500 rpm |
| Maximum Torque, Nm |
520 Nm @ 1200 – 1600 rpm |
| No. of Cylinder, Displacement |
4 cylinder, 3900CC |
| Emission Standard |
Bharat stage VI – OBD-2 |
Gearbox
| Gear Box Model & Type |
Improved G85, 6F+1R, Mechanical, Synchromesh Gears |
| Clutch Type |
Single Dry Plate, Hydraulic Control |
| Clutch Dia, Wear (mm) |
362, 3.6 |
| Power Take Off |
Optional |
Axle
| Front Axle |
IF 3.6 |
| Rear Axle |
DANA S 145 |
| Rear Axle Ratio |
4.56 (S), 6.33 (O) |
[/vc_tta_section][vc_tta_section i_icon_fontawesome=”fas fa-truck” add_icon=”true” title=”Chassis Frame & Suspension” tab_id=”1724237516931-64958853-53c9″]
| Frame Section (D x W x T) (mm) |
228 x 80 x 6
|
| Front Suspension |
Multileaf Spring
|
| Rear Suspension |
Multileaf Spring
|
| Anti-Roll Bar |
Front Standard, Rear Optional
|
[/vc_tta_section][vc_tta_section i_type=”linecons” i_icon_linecons=”vc_li vc_li-vynil” add_icon=”true” title=”Brakes” tab_id=”1724238753410-ff7f574e-cd12″]
| Service Brake |
Pneumatic Foot Operated, Dual Line with ABS |
| Parking Brake |
Spring Actuated with Hand Brake Valve @ cab |
| Front Brake Size (mm) & Type |
Ø 360 drum |
| Rear Brake Size (mm) & Type |
Ø 360 drum |
[/vc_tta_section][vc_tta_section i_type=”openiconic” i_icon_openiconic=”vc-oi vc-oi-steering-wheel” add_icon=”true” title=”Cabin & Steering” tab_id=”1724238922181-924a6148-2ef4″]
| Cabin |
Day Cabin |
| Steering Type |
Hydraulic Power Assisted |
[/vc_tta_section][vc_tta_section i_type=”openiconic” i_icon_openiconic=”vc-oi vc-oi-aperture-alt” add_icon=”true” title=”Tyres” tab_id=”1724395498122-e7ec8058-5e92″]
| Pattern & Size |
Radial tyres – 8.25R20 |
[/vc_tta_section][vc_tta_section i_icon_fontawesome=”fas fa-weight-hanging” add_icon=”true” title=”Weight” tab_id=”1724395570483-11b87397-61bc”]
| Gross Vehicle Weight – GVW |
13000 kgs |
[/vc_tta_section][vc_tta_section i_type=”typicons” i_icon_typicons=”typcn typcn-flow-switch” add_icon=”true” title=”Dimensions (mm): All Dimensions are for CBC” tab_id=”1724395588931-dc6e8c70-4c59″]
| Wheel Base (mm): |
3360 |
3760 |
4250 |
4800 |
| Loading Span(mm) |
4580 |
5275 |
6230 |
6780 |
| Overall Length (mm): |
6380 |
7075 |
8030 |
8580 |
| Overall Width (mm): |
2420 |
2420 |
2420 |
2420 |
| Overall Height (mm) (CBC): |
2500 |
2500 |
2500 |
2500 |
| Front Overhang (mm): |
1275 |
1275 |
1275 |
1275 |
| Rear Overhang (mm): |
1745 |
2040 |
2505 |
2970 |
| Ground Clearance (mm): |
245 |
245 |
245 |
245 |
[/vc_tta_section][vc_tta_section i_icon_fontawesome=”fas fa-tachometer-alt” add_icon=”true” title=”Performance” tab_id=”1724395630292-a2215831-47f1″]
| TCD (m) |
13.9 m |
14.8 m |
16.7 m |
18.7 m |
| Maximum Gradeability (%) |
6.33 RAR – 39.2% ; 4.56 RAR – 27% |
| Maximum Geared Speed (kmph) |
70 kmph |
70 kmph |
70 kmph |
70 kmph |
[/vc_tta_section][vc_tta_section i_icon_fontawesome=”fas fa-gas-pump” add_icon=”true” title=”Fuel Tank” tab_id=”1724739121740-db03b7b0-c722″]
| Fuel Tank / Filling Capacity (L) |
215L/200L |
For 3360 – 171L/160L |
| Adblue Tank / Filling Capacity (L) |
43L/ 36L |
43L/ 36L |
43L/ 36L |
43L/ 36L |
[/vc_tta_section][vc_tta_section i_icon_fontawesome=”fas fa-car-battery” add_icon=”true” title=”Electricals” tab_id=”1724836097558-b2183890-4643″]
| Battery Capacity (Ah) |
75Ah/100Ah(HAP) |
| Voltage (V) |
24V |
